Polyester Screen Mesh Fabric Roll for Screen Printing 65in Width with

Q: How do I choose between a 156 mesh and a 230 mesh?

Choose 156 mesh (62T) for general-purpose printing with good detail and moderate ink flow. Choose 230 mesh (90T) for very fine details, high-resolution halftones, or when you need a very thin ink deposit (common in "soft hand" prints).

Q: What width should I buy for standard screen frames?

In the U.S., the most common roll width is 50 inches (127cm) or 63 inches (160cm) . These widths allow you to efficiently cut pieces for standard 20x24 inch or 23x31 inch aluminum frames with minimal waste.

Your cart is empty

Continue shopping

Standard (5-7 business days) or Rush (2-3 business days).

7 days money back guarentee, buyer pays return shipping

Mesh Count		Thread Diameter (um)	Mesh opening (um)	Open Area (%)	Thickness (um)	Theoretic Ink Volume (cm3/m2)	Max Tension (N/CM)
Count/cm	Count/inch	Thread Diameter (um)	Mesh opening (um)	Open Area (%)	Thickness (um)	Theoretic Ink Volume (cm3/m2)	Max Tension (N/CM)
43	110	80	153	43	130	56	35-40
47	122	70	130	40	113	45	35-40
53	135	55	133	50	86	42	28-33
64	160	55	101	37	98	36	28-32
72	180	48	94	46	80	37	30-35
80	200	48	77	38	92	35	30-35
90	230	48	66	35	85	30	30-35
100	250	40	55	32	68	22	26-29
110	280	40	47	26	69	18	26-30
120	305	40	38	20	65	13	27-32
140	350	34	32	19	58	11	30-33
150	380	31	21	21	45	13	28-31
165	420	31	22	22	54	12	26-29

Product Overview

Achieve professional-grade precision with our High Strength Polyester Screen Printing Mesh. Engineered for industrial screen printing, this mesh features high-stability, low-elongation monofilament polyester to ensure consistent tension and perfect registration for every print.

Technical Specifications

Feature	Specification
Material	100% High-Strength Polyester Monofilament
Mesh Counts	Available from 110 to 420 Mesh per Inch
Tension	High-Stability, Low-Elongation
Applications	Textiles, PCB, Graphic & Industrial Printing

Why Choose Our Screen Mesh?

Consistent Ink Deposit: Precision-woven threads ensure uniform ink flow, crucial for both fine lines and heavy solids.
Excellent Adhesion: Specially treated surface for superior emulsion adhesion, reducing stencil breakdown during long runs.
Durable & Reliable: Resistant to solvents and mechanical abrasion, designed for high-volume textile and DTF production.

Pro Tip: Pair this mesh with our professional-grade squeegee blades and alumium frame to achieve optimal print quality and edge definition.

Applications:

This screen printing mesh is versatile and suitable for a wide range of applications across different industries. Whether you're printing on textiles, plastics, glass, ceramics, or metals, this mesh ensures exceptional results. Use it for clothing fabric printing to achieve detailed and vibrant designs on t-shirts, hoodies, and other apparel items. In plastic film printing, it offers excellent ink adhesion and clarity for packaging, labels, and promotional materials.

Additionally, this mesh is suitable for newspaper printing, ensuring clear and legible text and images. Its low moisture absorption properties prevent ink smudging, ensuring consistent print quality even in humid conditions. Overall, the 305 Mesh Count 65" Screen Printing Mesh with Yellow is an excellent choice for businesses looking to achieve high-quality prints across various substrates.

✮ High Tension: The fracture resistance is high, and the tension value of the printing mesh is significantly higher than that of the ordinary printing mesh

✮ High Stability: The tension remains very stable during the printing process, thus ensuring the printing quality and the service life of the screen.

✮ High abrasion resistance: The high-quality fiber is used as the raw material, and the surface
of the screen is specially treated to withstand high pressure and multiple frictions.
Therefore, the screen has high safety and printing resistance.

✮ Exceptional Print Quality: This mesh delivers outstanding print quality with excellent color accuracy and fine detail reproduction.

✮ Versatile Applications: Suitable for printing on textiles, plastics, glass, ceramics, metals, and more, offering versatility in printing applications.

✮ Durable Construction: Constructed with high-quality materials, this mesh offers durability and longevity, ensuring reliable performance over time.

✮ Low Moisture Absorption: The mesh has low moisture absorption properties, preventing ink smudging and ensuring consistent print quality in various environmental conditions.

✮ Easy to Use: Designed for ease of use, this mesh can be easily integrated into existing printing workflows, making it suitable for both beginners and experienced printers

Mesh Count		Thread Diameter (um)	Mesh opening (um)	Open Area (%)	Thickness (um)	Theoretic Ink Volume (cm3/m2)	Max Tension (N/CM)
Count/cm	Count/inch	Thread Diameter (um)	Mesh opening (um)	Open Area (%)	Thickness (um)	Theoretic Ink Volume (cm3/m2)	Max Tension (N/CM)
43	110	80	153	43	130	56	35-40
47	122	70	130	40	113	45	35-40
53	135	55	133	50	86	42	28-33
64	160	55	101	37	98	36	28-32
72	180	48	94	46	80	37	30-35
80	200	48	77	38	92	35	30-35
90	230	48	66	35	85	30	30-35
100	250	40	55	32	68	22	26-29
110	280	40	47	26	69	18	26-30
120	305	40	38	20	65	13	27-32
140	350	34	32	19	58	11	30-33
150	380	31	21	21	45	13	28-31
165	420	31	22	22	54	12	26-29
